Single Sign-On and the Corporate Directory, Part III
Welcome to the third installment of how to implement a single sign-on and corporate directory system. In this article, we tackle integrating Microsoft Windows clients. There's a lot involved to make it all happen, so put on your work gloves and let's get to it.
When you want to integrate Windows clients into a heterogeneous environment, you have some choices to make. Although you can run an Active Directory (AD) server and have your Linux and Apple clients bind to it for authentication and identity management, the costs involved are not minimal. It also wouldn't make for an interesting article on an open-source single sign-on and directory implementation.
When you're binding Windows clients to an open-source solution, you have two more choices to make. Do you bind them to the Kerberos realm for authentication or do you bind them to LDAP for identity management? This is an either/or choice because although Windows clients know how to speak both Kerberos and LDAP, they know how to speak them at the same time only when talking to an AD server. In other words, Windows clients can talk to a non-AD Kerberos server only when the user's identities are kept locally. Likewise, a Windows client can get identities from LDAP via Samba, but only when the passwords are also served via Samba, and Samba can't, at the moment, authenticate via Kerberos.
Having Windows authenticate against our Kerberos KDC is easier to set up, but it could be harder to maintain because every user who uses the Windows client needs to have a local account. This is fine if all you have is one Windows client to maintain, but if you have any more than that, you'll need to add every user to every client. I won't explore this option; however, if you're interested you should pick up Jason Garman's Kerberos: The Definitive Guide.
Because we're dealing with a corporate directory, I'm assuming you probably have more than one Windows machine on your network. In order to make using them and incorporating them as painless as possible, we use Samba tied to our LDAP directory as a back end. Even though we'll be configuring Samba a little differently, you should first read Craig Swanson and Matt Lung's “OpenLDAP Everywhere Revisited” (see the on-line Resources), as it will give you a good foundation on which to build. I created an organizational unit branch in the directory named samba for Samba specific entries such as machines and ID maps. Listing 1 shows the hierarchy of these special branches, and Listing 2 shows the LDIF for them.
Listing 1. Additional Organizational Units
+ o=ci,dc=example,dc=com |- ou=samba |- ou=hosts |- ou=idmap
Listing 2. LDIF for Additional Organizational Units
dn: ou=samba,o=ci,dc=example,dc=com objectClass: organizationalUnit ou: samba dn: ou=hosts,ou=samba,o=ci,dc=example,dc=com objectClass: organizationalUnit ou: hosts dn: ou=idmap,ou=samba,o=ci,dc=example,dc=com objectClass: organizationalUnit objectClass: sambaUnixIdPool uidNumber: 15000 gidNumber: 15000
I don't use the smbldap scripts from IDEALX for creating necessary entries, because I'm using LDAP for more than just Samba authentication. One main reason for not using the smbldap tool is because it assumes that it and Samba will be the only point for actions such as adding users and groups. In my environment, all users don't have the ability to log in to Windows machines. Some users may start off as Linux-only users, but then need to be given access to Windows machines later. The smbldap tools don't handle this case very well. However, the smbldap tools do handle other things nicely, so like all things, investigate all the tools available and choose the best one(s) suited to your needs.
We need several users in LDAP that will do various tasks. First we need a user who has write access to certain pieces of the directory. If you notice in /etc/samba/smb.conf, there is an option, ldap admin dn, that defines the DN of this user. This user, named samba_server, should be stored in the LDAP directory itself, and it will be the only user in the directory with a password associated with it. Because this user isn't of the posixAccount objectClass, the account is not recognized under Linux. To create this user, first run slappasswd to generate the hashed password. Then, take the hash and create an ldif file that's similar to Listing 3.
